Climbing Drum Peel Fixture, ASTM-D1781

Peel and Adhesion Test Fixtures

JLWForce

{formbuilder:40269}

Description

A climbing drum test is a typical peel testing method used to determine the de-lamination characteristics of adhesives used to bond different materials together.

This test covers the determination of the peel resistance of adhesive bonds between a relatively flexible adherent and the relatively flexible facing of a sandwich structure and its core.


The fixture consists of a flanged drum, flexible loading straps connected to an adapter, and clamps for holding the test specimen.

Specifications
  • Standard: ASTM-D1781
  • Drum diameter: 102 mm (4 in.)
  • Maximum Sample Width: 80 mm
  • Load Capacity: 5 kN
  • Weight: 3 kg
  • Material: Aluminum and steel
  • Surface: Eloxat Nickel
  • Connection: 15.9 mm (5/8") female eye end - Adapters for other sizes



The following information is needed to quote this fixture.
  • An additional grip tensile grip is required for the upper pull. Will you need pricing on the top grip?
  • Do you need a full system or just the fixture?
  • If you already have a test stand and are looking to only add the fixture please provide information on the connection requirements of your test stand.



       Climbing Drum Dimensional Drawing ASTM-D1781
