Peel and Adhesion Test Fixtures

15 products

Showing 1 - 15 of 15 products

These fixtures are designed to test adhesives, tapes, bonded structures and laminated surfaces. Fixtures available to test 90 degree, 45 degree (yogurt foil peel), loop tack peel, climbing drum fixture.

Connections on these grips and fixtures are threaded or have a female eye end. Grips and fixtures with a female eye end will have a 5/8" or 1.25" diameter. These sizes are standard for Lloyd Instruments, Chatillon, and Mark-10 equipment. We also sell these brands of test stands, load cells, and force gauges to use with our grips and fixtures.

We have adapters to fit our grips and fixtures to any test stand brand including Instron, MTS, Zwick, Shimpo, and more.

If you need assistance to determine which grip, fixture or adapter is needed, please contact us.

Showing 1 - 15 of 15 products

JLWForce 90 Degree Peel Fixture, ASTM-D3330, ASTM-D6862, ASTM-D6252

SKU: PEEL-50

Force capacity: 5 kN (450 lbF)
Specimen width max.: Max. 50 mm
Specimen length max.: Max. 280 mm
Standards: ASTM-D3330, ASTM-D6862, ASTM-D6252, ASTM-B571, ASTM-D2861

$1,905.00 USD

G1109, 90°/45°/30° Peel Fixtures, Peel Fixture, Mark-10

Mark-10 Mark-10 G1109 90° Peel Testing Fixture, 45° & 30° Optional

SKU: G1109

ASTM D6862 / D3330 / D903
Capacity: 100 lbF (500 N)

$2,033.00 USD $2,140.00 USD

Roller Peel Fixture, ASTM D3167, Peel Fixture, JLWForce

JLWForce Roller Peel Fixture for Adhesive Bond Testing, ASTM D3167

SKU: JLW105-D254-B254

Roller diameter: 25.4 mm (1 in.)
Roller width: 25.4 mm (1 in.)

$1,099.00 USD

JLWForce Floating Roller Peel Fixture DIN 1464 DIN 53289 ISO 4578

SKU: PF105-D25-W30

Roller diameter: 25 mm
Roller width: 30 mm

$925.00 USD

JLWForce Roller Peel Fixture PF192 with Adjustable Angle DIN EN1372, ISO22631

SKU: PF192-20, PF192-25

Roller diameter: 20 or 25 mm
Roller width: 57 mm

$1,060.00 USD

JLWForce Peel Fixture to ISO-IEC10373-1, Test ID Card, Credit Cards

SKU: JLW104-10373

$1,081.00 USD

Film and Paper Grips, Vice Grips, Mark-10

Mark-10 Mark-10 Film and Paper Grips G1008, G1015-1/-2/-3

SKU: G1008, G1015-1, G1015-2, G1015-3

Force capacity: 500 N (100 lbF)
Jaw width (in): 1, 3, 5, 7
Jaw type: Serrated
Opening: 0-30 mm
Weight: 0.14-0.41 kg (0.31-0.9 lbs)

From $285.00 USD $300.00 USD

Mark-10 Mark-10 Miniature Film and Paper Peel Grip G1124

SKU: G1124

Force capacity: 250 N (50 lbF)
Opening: 0 - 3.8 mm (0-0.15 in)
Weight: 0.04 kg (0.08 lb)

$256.50 USD $270.00 USD

Climbing Drum Peel Fixture, Peel Fixture, JLWForce

JLWForce Climbing Drum Peel Fixture, ASTM-D1781

SKU: JLW115-D102

JLWForce Flatwise Tensile Strength Adhesion Fixture

SKU: JLW113-25.4, JLW113-50, JLW113-50.8, JLW113-76.2, JLW113-100

Fixture for testing flatwise tensile strength and tensile adhesion properties according to ASTM C297, ASTM D3354, ASTM D1623B, EN 1607, EN 2243-4, DIN 53292.

From $1,771.00 USD

JLWForce Additional inserts for Flatwise Tensile Strength Adhesion Fixture

SKU: INSERT-JLW113-25.4, INSERT-JLW113-50, INSERT-JLW113-50.8,...

From $315.00 USD

G1098 ASTM D6195 Loop Tack Fixture, Peel Fixture, Mark-10

Mark-10 Mark-10 G1098 ASTM D6195 Loop Tack Fixture

SKU: G1098

Capacity: 100 lbF [500 N]
Standard: ASTM D6195
Testing pressure sensitive flexible substrates

$931.00 USD $980.00 USD

Yogurt Foil Peel Fixture, 30, 45 or adjustable angle, Peel Fixture, JLWForce

JLWForce Yogurt Foil Peel Fixture, 30, 45 or adjustable angle

SKU:

JLWForce Handheld Sample Cutter, 1 inch Film, ASTM F88, ASTM D882

SKU: SP1232-25.4

$785.00 USD

JLWForce Peel Strength Test Roller According to ASTM-D3330

SKU: PF989-95-45

$695.00 USD
