JLWForce

• Clamping Force: 2.2 kN / 7 bar - max 5 kN / 16 bar

• Force capacity:  250 lbF [1.2 kN]
• Jaw opening: 0-0.4 in [0-10 mm]

• 5/8" [15.8 mm] male eye end with 8 mm pin
• 1.25" [31.8 mm] female eye end with 12.8 mm diameter clevis pin

• Load capacity: 10,000 lbf (50 kN)
• Body: Aluminum
• Top Fixture Length: 240 mm
• Bottom Fixture Lengths: 360 mm, 500 mm, 700 mm

• Force capacity: 1 kN (200 lbF)
• Jaw dimensions: 10 x 25 mm
• Jaw types: Pyramid and Rubber

• 5/8" [15.8 mm] male eye end with 8 mm pin
• 5.9 mm eye end post, 2.5 mm Clevis pin

• Capacity: 2,250 lbF [10 kN]
• Opening: 0-0.3 in [0-8 mm]
• Jaw Width: 1.2 in

• Dies A, B, C, D
• 12x59, 6x59, 6x33, 3x33 mm

• Flexible packaging and battery separator film
• Opening: 10 mm Ø
• Probe:  0.8 mm Ø
• Max specimen thickness: 3 mm

• Tensile force: 2 kN / 7 bar
• Clamping force: 1.9 kN
• Sample size: 0-2 mm

• Tensile force: 1 kN
• Clamping force: 2 kN (horizontal) at 7 bar
• Opening: 0-6 mm

• 1.25" (317 mm mm) male eye end, 1/2" (12.8 mm) pin
• 35 mm male eye end, 13 mm pin
• Compatible with Shimadzu 50 kN test stands

• Load capacity: 2,000 lbf (10 kN)
• Body: Steel
• Span: Adjustable from 4 mm -170 mm

• 5/8" [15.8 mm] male eye end with 8 mm pin
• M20 x 1.5 mm male thread

• Force capacity: 20 kN (4,000 lbF)
• Jaw size (mm): 40 x 60
• Jaw types: Pyramid
• Opening: 0-32 mm (1.26 in)
• Weight: 5.37 kg (11.8 lbs)

Fixture for testing flatwise tensile strength and tensile adhesion properties according to ASTM C297, ASTM D3354, ASTM D1623B, EN 1607, EN 2243-4, DIN 53292.

• Force capacity: 100 N (20 lbF)
• Opening: 0 - 3 mm

• Capacity: 20 kN [4,000 lbF]
• Jaw width: 40 mm

• 5/8" [15.8 mm] male eye end with 8 mm pin
• M12x1.75 male thread

• 5/8" (15.8 mm) male eye end, 8 mm pin
• M30x2 male thread

• 1.25" (317 mm mm) male eye end, 1/2" (12.8 mm) pin
• 35 mm male eye end, 13 mm pin
• Compatible with Shimadzu 50 kN test stands

• 5/8" [15.8 mm] male eye end with 8 mm pin
• 35 mm male eye end with 13 mm pin
• Compatible with Shimadzu 50 kN test stands

Lead time: 6 weeks

• Force capacity: 500 lbF [2.5 kN]
• Jaws: 25 x 25 mm, 25 x 50 mm

• 5/8" [15.8 mm] male eye end with 8 mm pin
• M12x1.75 female thread

• Force capacity:  4,000 lbF [20 kN]

• Force capacity:  1,000 lbF [5 kN]

• Force capacity:  2,000 lbF [10 kN]

• Male-Type D, 1.25 in. [31.7 mm] male eye end with 1/2 in. [12.8 mm] pin
• 1"-14 Male Thread

• Capacity: 5 kN [1000 lbF]
• Pyramid (Serrated) Roller
• Roller Width: 100 mm

• Capacity: 100 kN [22,500 lbF]
• Jaw width: 100 mm

• Standards: ASTM D7249, ASTM C393

• Male-Type D, 1.25 in. [31.7 mm] male eye end with 1/2 in. [12.8 mm] pin
• 1"-14 Male Thread

• Dimensions: 200x200 mm
• Platen has concentric grooves to aid in centering of sample
• 6 mm Ø holes spaced at 20 mm

• 5/8" [15.8 mm] male eye end with 8 mm diameter pin
• M16X2-L40 external thread
